Ardent battery box –DC BOX
Click image above to go to the product page.
The box is designed to protect the battery not to charge the battery. You will need a separate charger for this.
To charge the battery through the box you will need to use a charger with an Anderson plug attached to it. (click here for recommended chargers) You are required to have the Isolation switch turned on for it to charge.
There is a LED display on the front of the box to show you the status and voltage of the battery.
There are 4 Anderson outputs (plugs) to plug things like fridges etc into.
| Suitable Battery Types | Lithium, AGM, Calcium, Wet, Gel. |
| Body Materials | ABS plastic (meets UL 94V-0 standard). |
| Charge Method | Via Anderson plug input. |
| Port | 1x Dual USB output 2x Cigarette plug outputs 4x 50A Anderson plug inputs/outputs 1x 175A Anderson plug output |
| Max Battery Size | 330mm (L) x 175mm (W) x 220mm (H) |
| Max Battery Weight | 35kg |
| Cut-out Voltage | 12.7v |
| Box Dimensions | 455mm (L) x 240mm (W) x 330mm (H) |
Ardent Battery Box with DCDC
Click image above to go to the product page.
This battery box is very similar to the standard battery box however there are a few differences.
This box has a DCDC charger on top which means that when this is wired up to a Vehicle the dcdc charger will kick in and charge the battery while on the go. This is done via the alternator.
When the vehicle stops you can continue to charge this battery via solar panels. The solar panels are connect to the side of the box via the YELLOW Anderson plugs.
The BLUE Anderson plugs are for the DCDC charger to connect to the cars starting battery.
The extra Anderson plug ports allows you to still have 4 free Anderson plugs for use of your accessories.
| Suitable Battery Types | Lithium, AGM, Calcium, Wet, Gel |
| Body Materials | ABS plastic (meets UL 94V-0 standard) |
| Charge method | via Anderson plug input |
| Port |
1x Dual USB output 1 x 30AMP DC Input 1 x 30AMP DC Output (Max 25V) 2x Cigarette plug outputs 2x 50A Anderson plug inputs/outputs 1x 175A Anderson plug output\ 1 X 30AMP DC/DC Charger |
| Max Battery Size | 330mm (L) x 175mm (W) x 230mm (H) |
| Max Battery Weight | 35kg |
| Box Dimensions | 455mm (L) x 240mm (W) x 330mm (H) |
Ardent battery box with 1200w inverter
Click image above to go to the product page.
This battery box comes with an inverter which means you can charge 240v electrics. Like your laptop phone hair straighteners etc.
•Ac power – Alternating current
•1DC power – direct current
This box features multiple inputs on the side so you can plug a 240V Australian plug into this box, as well as 4 Anderson plugs 2 Anderson outputs, 2 USB and 2 cig ports.
| Suitable Battery Types | Lithium, AGM, Calcium, Wet, Gel |
| Body Materials | ABS plastic (meets UL 94V-0 standard) |
| Charge method | via Anderson plug input |
| Port |
1x Dual USB output 1 X 1200W Inverter |
| Max Battery Size | 330mm (L) x 175mm (W) x 230mm (H) |
| Max Battery Weight | 35kg |
| Box Dimensions | 455mm (L) x 240mm (W) x 330mm (H) |
Common questions..
Q: What battery fits in the Battery box
A: Our AGM Giant 140's as well as our Giant Lithium 140's and 170's.
Q: What can be plugged into an Anderson port?
A: Anything with a 50amp Anderson plug on it this is mainly camping fridges or car accessories or RV.
Q: Can I connect my DCDC charger with the inverter battery box?
A: Yes a DCDC charger can be connected to any of our boxes.
Q: Why is an inverter needed?
A: this changes the DC to AC. This means that you can then plug in any household item to the box (with a standard Australian household plug) We recommend that you check the voltage draw on the item you are plugging in, as this is a 1000W inverter. Everything else is a direct current and would need to be plugged into the Anderson plug.
Q: Are the Anderson plugs input or output?
A: They are both.
